Power Supply: 24V, 0.3A Gigabit PoE Adapter (Included)

Max. Power Consumption: 7W

Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)

Supported Voltage Range: 24V ± 10%

Gain 26 dBi

Networking Interface (1) 10/100/1000 Ethernet Port

Processor Specs MIPS 74Kc

Memory 64 MB DDR2

LEDs Power, Ethernet

Channel Sizes

PtP Mode: 10/20/30/40/50/60/80 MHz

PtMP Mode: 10/20/30/40 MHz

Enclosure Characteristics Reflector (Aluminum) / Plastic: PC

Mounting Pole-Mounting Kit (Included)

Wind Loading 550 N @ 200 km/h (123.6 lbf @ 125 mph)

Wind Survivability 200 km/h (125 mph)

ESD/EMP Protection ± 24 kV Contact / Air

Operating Temperature -40 to 70° C (-40 to 158° F)

Operating Humidity 5 to 95% Non-condensing

Certifications CE, FCC, IC



Specifications

Features

Antenna Gain – dBi                    26

Antennas                                    Yes

Indoor or Outdoor                       Outdoor

Color                                            White

Other features

Country of Origin                        China

Type of Packaging                     Retail Box

Warranty                                     1 Year Limited
