3 Zone one-way page control

Provides tandem all call

Background music input, automatically mutes in zone being paged

Page override for special priority announcements

Features are programmable per zone

Built-in tone generator for night ringing, time clock tone, doorbell

Accepts pulse and tone dial

Battery back-up input

UL listed

To interface with analog extension or Centrexline add the VC-V-9970

Access: page port on selected telephone systems, PBX loop start or ground-start trunk port, electronic or 1A2 line key (line card required), or dedicated single line phone set

Input impedance: 600 ohm

Music source impedance: 4 to 600 ohm

Music input level: -10dBm nominal

DC output: -24 Vdc @ 500 mA

Power requirements: 230 Vac/.5A or 120 Vac/1A

Weight: 6.25lbs

Dimensions: 7.1"H x 10"W x 3"D



Specifications

Features

Number of Zones                                          3

Paging Adapters and Zone Controllers        Yes

Color                                                               White

Environmental features

Energy Star Qualified                                    No

Recycled Packaging                                      Yes

Other features

Country of Origin                                           USA

RoHS Compliant                                            No

Type of Packaging                                        White Box

Warranty                                                        1 year
